316L Stainless Steel Strip
316L Stainless Steel Strip belongs to the austenitic stainless steel series. 316 grade has a higher nickel content than 304 grade, and therefore has stronger corrosion resistance than 304 grade.
316L Stainless Steel Strips are made using rigorous processes. 316L Stainless Steel Strips are of exceptional quality and are particularly suitable for harsh environments. Due to its sustainability, it is used in a wide range of industries and industrial machinery. It maintains extreme strength even at extremely high temperatures. However, it is a major buyer because of its durability. 316L Stainless Steel Strips are widely used in the cement industry, power projects, infrastructure development, turbines, shaft industry, heavy machinery, etc.
Product Description
| Grade | 316L |
| Standard | ASTM/EN/JIS |
| Thickness | 0.03mm – 3.0 mm |
| Width | 1.5mm – 600 mm |
| Length | coil type, or it can be produced according to customer requirements |
| Surface Finish | NO.1, 2B, 2H (Rerolled Bright), BA, No.4, 8K (Mirror), HL (Hairline), Polishing Bright, etc |
| Edge | Mill Edge, Slit Edge, Deburred Edge, Round Edge, V Type Edge |
316L Stainless Steel Strip Chemical Composition
| Grade | Spec. | Range | %C | %Si | %Mn | %P | %S | %Cr | %Ni | %Mo | %Ti | %N |
| 316L | ASTM A240 | Min. | 16.00 | 10.00 | 2.00 | – | – | |||||
| 316L | ASTM A240 | Max. | 0.03 | 0.75 | 2.00 | 0.045 | 0.03 | 18.00 | 14.00 | 3.00 | – | 0.10 |
Physical Properties
| Physical Properties | At 70°F | At 20°C |
| Density | 0.29 lb./in³ | 7.99 g/cm³ |
| Modulus of Elasticity (E) | 28.0 x 10³ ksi | 193 x 10³MPa |
| Coefficient of Expansion | 8.9 x 10⁻⁶ microinches/in.-°F (32-212°F) | 16.0 μm/m-°C (0-100°C) |
| Electrical Resistivity | 29.4 μ ohm. in | 74 μ ohm.cm |
| Thermal Conductivity | 9.4 Btu-in./ft.²hr.-°F (100°C) | 16.2 W/m-K (100°C) |
Typical Mechanical Properties
Typical mechanical properties are based on the AK source, ASTM A240.
| Condition | Tensile Strength Min (UTS) | 0.2% YS Min | Elongation% in 2” Min (50.8 mm) | Hardness Rockwell |
| Annealed (Min) | 81 ksi (558 MPa) | 42 ksi (290 MPa) | 50% | 79 HRBW (Max) |
* Tempered Properties available upon request
316l Stainless Steel Strip Application
- 316l Stainless Steel Strip Used in Tractor
- 316l Stainless Steel Strip Used in Automotive Trim
- 316l Stainless Steel Strip Used in Stamped Machined Products
- 316l Stainless Steel Strip Used in Cookware
- 316l Stainless Steel Strip Used in Appliances
- 316l Stainless Steel Strip Used in Kitchen
- 316l Stainless Steel Strip Used in Foodservice Equipment
- 316l Stainless Steel Strip Used in Sinks
- 316l Stainless Steel Strip Used in Railway Cars
- 316l Stainless Steel Strip Used in Trailers
Application
Agricultural Modernization
Construction Engineering
Environmental Protection Engineering
Food Processing Industry
Intelligent Home Appliances
Medical and Health Field
New Energy Infrastructure
